Technical Reference

Technical Specifications

AttributeValue
Supply Voltage12 V to 24 V
Output TypePNP
Maximum Operating Temperature85
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP69K, IP68
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread SizeM12 x 1
Terminal Type4-Pin M12 Connector
Housing MaterialStainless Steel 316L
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max24 V
Application
Communication Interface
Sensing Distance6 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length60
Switching Frequency Max0.05 kHz
Dimensions
Width12
Electrical Connection4-Pin M12 Connector
