Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM12 x 1
Terminal Type4-Pin M12 Connector
Housing MaterialPPS, Brass, Metal
Body StyleCylindrical
Supply Voltage20 V to 264 Vac/dc
Output Type
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP69K, IP68
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Supply Voltage AC240 V
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max240 V
Application
Communication Interface
Sensing Distance2 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload Protection
Length54 mm
Switching Frequency Max1 kHz
Dimensions
Width17 mm
Electrical Connection4-Pin M12 Connector
