Technical Reference

Technical Specifications

AttributeValue
Supply Voltage20 V to 264 Vac/dc
Output Type
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP69K, IP68
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread SizeM18 x 1
Terminal Type4-Pin M12 Connector
Housing MaterialPPS, Brass, Metal
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Supply Voltage AC240 V
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max240 V
Application
Communication Interface
Sensing Distance5 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current300 mA
Short Circuit Overload Protection
Length56.15
Switching Frequency Max1 kHz
Dimensions
Width24
Electrical Connection4-Pin M12 Connector
