Technical Reference

Technical Specifications

AttributeValue
Supply Voltage12 V to 24 V
Output TypeNPN
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingShielded
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread SizeM12 x 1
Terminal TypeCable
Housing MaterialBrass
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max24 V
Application
Communication Interface
Sensing Distance2 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current
Short Circuit Overload Protection
Length42
Switching Frequency Max2 kHz
Dimensions
Electrical ConnectionCable
