Technical Reference

Technical Specifications

AttributeValue
Mounting TypeNon-flush
Thread SizeM12 x 1
Terminal TypeM20 Terminal
Housing MaterialBrass
Body StyleCylindrical
Supply Voltage12 V to 24 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingShielded
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max24 V
Application
Communication Interface
Sensing Distance4 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current
Short Circuit Overload Protection
Length52
Switching Frequency Max1 kHz
Dimensions
Electrical ConnectionM20 Terminal
