Technical Specifications

AttributeValue
Supply Voltage12 V to 48 V
Output TypeNPN
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread SizeM30
Terminal Type4-Pin M12 Connector
Housing MaterialPlastic
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max48 V
Application
Communication Interface
Sensing Distance10 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length55
Switching Frequency Max1.5 kHz
Dimensions
Electrical Connection4-Pin M12 Connector
