Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM8 x 1
Terminal TypeCable
Housing MaterialBrass
Body StyleCylindrical
Supply Voltage12 V to 24 V
Output TypeNPN
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingShielded
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max24 V
Application
Communication Interface
Sensing Distance1.2 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current
Short Circuit Overload Protection
Length62
Switching Frequency Max3 kHz
Dimensions
Electrical ConnectionCable
