Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM18 x 1
Terminal TypeCable
Housing MaterialPlastic
Body StyleCylindrical
Supply Voltage12 V to 48 V
Output TypeNPN
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max48 V
Application
Communication Interface
Sensing Distance8 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length62
Switching Frequency Max1.5 kHz
Dimensions
Electrical ConnectionCable
