Technical Reference

Technical Specifications

AttributeValue
Supply Voltage12 V to 24 V
Output TypePNP
Maximum Operating Temperature50
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-25
IP RatingIP69K, IP67
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread SizeM30 x 1.5
Terminal Type5-Pin M12 Connector
Housing MaterialBrass
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max24 V
Application
Communication Interface
Sensing Distance20 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length50
Switching Frequency Max0.5 kHz
Dimensions
Electrical Connection5-Pin M12 Connector
