Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread Size
Terminal Type2m Cable, 3-Wire
Housing MaterialPBT, Plastic
Body StyleRectangular
Supply Voltage12 V to 48 V
Output Type
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP65, IP69K, IP67
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Depth40
Hazardous Area Certification
Standards/ApprovalsIEC 60068-2-6, IEC 60529, UL Certificate, CCC Certificate, IEC 60068-2-27, DIN 40050, CSA Certificate
BrandTelemecanique Sensors
Supply Voltage DC Max48 V
Application
Communication Interface
Sensing Distance15 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current100 mA
Short Circuit Overload ProtectionYes
Length40
Switching Frequency Max0.3 kHz
Dimensions40 x 70 x 40 mm
Width70
Electrical Connection3-Wire, 2 m Cable
