Please note: Some technical details are unavailable for this product

Technical Specifications

AttributeValue
Supply Voltage12 V to 48 V
Output TypePNP
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP69K, IP67
Reverse Polarity Protection
Mounting TypeFlush
Thread SizeM12 x 1
Terminal Type4-Pin M12 Connector
Housing MaterialPPS, Nickel Plated Brass
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/ApprovalsCSA, UL Certified, CE, CCC
BrandTelemecanique Sensors
Supply Voltage DC Max58 V
Application
Communication Interface
Sensing Distance2 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current100 mA
Short Circuit Overload ProtectionYes
Length61 mm
Switching Frequency Max4 kHz
Dimensions
Electrical Connection4-Pin M12 Connector
