Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM30 x 1.5
Terminal TypeM5 Connector
Housing MaterialPPS, Brass, Metal
Body StyleCylindrical
Supply Voltage12 V to 48 V
Output Type
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP69K, IP68
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max48 V
Application
Communication Interface
Sensing Distance15 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current100 mA
Short Circuit Overload ProtectionYes
Length53.75 mm
Switching Frequency Max0.5 kHz
Dimensions
Width36 mm
Electrical ConnectionM5 Connector
