Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM18 x 1
Terminal Type4-Pin M12 Connector
Housing MaterialMetal
Body StyleCylindrical
Supply Voltage12 V to 24 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP65, IP67
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max24 V
Application
Communication Interface
Sensing Distance8 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length40.15
Switching Frequency Max1 kHz
Dimensions
Width24
Electrical Connection4-Pin M12 Connector
