Technical Reference

Technical Specifications

AttributeValue
Mounting TypeNon-flush
Thread SizeM18 x 1
Terminal TypeCable
Housing MaterialPPS, Brass, Metal
Body StyleCylindrical
Supply Voltage12 V to 48 V
Output TypeNPN
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP69K, IP68
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max48 V
Application
Communication Interface
Sensing Distance12 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length63.5
Switching Frequency Max1 kHz
Dimensions
Width24
Electrical ConnectionCable
