Technical Reference

Technical Specifications

AttributeValue
Supply Voltage12 V to 48 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP69K, IP67
Reverse Polarity ProtectionYes
Mounting TypeNon-flush
Thread SizeM30 x 1.5
Terminal Type3-Pin M8 Connector
Housing MaterialPPS, Brass, Metal
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max48 V
Application
Communication Interface
Sensing Distance22 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length74.25
Switching Frequency Max0.5 kHz
Dimensions
Width36
Electrical Connection3-Pin M8 Connector
