Technical Reference

Technical Specifications

AttributeValue
Mounting TypeNon-flush
Thread SizeM30 x 1.5
Terminal Type3-Wire Cable
Housing MaterialPPS, Brass, Metal
Body StyleCylindrical
Supply Voltage20 V to 264 Vac/dc
Output Type
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP69K, IP67
Reverse Polarity Protection
ManufacturerTelemecanique Sensors
Shape
Series
Supply Voltage AC240 V
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max240 V
Application
Communication Interface
Sensing Distance22 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current300 mA
Short Circuit Overload Protection
Length74.25
Switching Frequency Max0.3 kHz
Dimensions
Width36
Electrical Connection3-Wire Cable
