Technical Reference

Technical Specifications

AttributeValue
Mounting TypeNon-flush
Thread SizeM12 x 1
Terminal Type4-Pin M12 Connector
Housing MaterialPPS
Body StyleCylindrical
Supply Voltage10 V to 36 V
Output TypePNP/NPN
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max36 V
Application
Communication Interface
Sensing Distance4 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length61
Switching Frequency Max5 kHz
Dimensions
Electrical Connection4-Pin M12 Connector
