Technical Specifications

AttributeValue
Mounting TypeNon-flush
Thread SizeM12 x 1
Terminal TypeCable
Housing MaterialPPS
Body StyleCylindrical
Supply Voltage20 V to 264 Vac/dc
Output Type
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP68
Reverse Polarity Protection
ManufacturerTelemecanique Sensors
Shape
Series
Supply Voltage AC264 V
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max264 V
Application
Communication Interface
Sensing Distance4 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current300 mA
Short Circuit Overload Protection
Length61
Switching Frequency Max5 kHz
Dimensions
Electrical ConnectionCable
