Technical Reference

Technical Specifications

AttributeValue
Mounting TypeNon-flush
Thread SizeM12 x 1
Terminal Type4-Pin M12 Connector
Housing MaterialPPS, Nickel Plated Brass
Body StyleCylindrical
Supply Voltage12 V to 24 V
Output TypeNPN
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-25
IP RatingIP65, IP69K, IP67
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/ApprovalsCSA, UL Certified, CE, E2
BrandTelemecanique Sensors
Supply Voltage DC Max24 V
Application
Communication Interface
Sensing Distance8 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length37
Switching Frequency Max2 kHz
Dimensions
Electrical Connection4-Pin M12 Connector
