Technical Reference

Technical Specifications

AttributeValue
Supply Voltage12 V to 24 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-25
IP RatingIP65, IP67
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread SizeM18 x 1
Terminal Type3-Pin M8 Connector
Housing MaterialNickel Plated Brass
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/ApprovalsCSA, UL Certified, CE, IEC 60068-2-6, IEC 60529, IEC 60068-2-27
BrandTelemecanique Sensors
Supply Voltage DC Max24 V
Application
Communication Interface
Sensing Distance5 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length53
Switching Frequency Max1.2 kHz
Dimensions
Electrical Connection3-Pin M8 Connector
