Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM18 x 1
Terminal TypeCable
Housing MaterialNickel Plated Brass
Body StyleCylindrical
Supply Voltage12 V to 24 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-25
IP RatingIP67, IP68
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/ApprovalsCSA, CE, UL, IEC 60068-2-6, IEC 60529, E2, EN/IEC 61508, IEC 60068-2-27, EN/ISO 13849-1
BrandTelemecanique Sensors
Supply Voltage DC Max24 V
Application
Communication Interface
Sensing Distance5 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length41
Switching Frequency Max2 kHz
Dimensions
Electrical ConnectionCable
