Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 36 V
Output TypePNP/NPN
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP68
Reverse Polarity ProtectionYes
Mounting TypeNon-flush
Thread SizeM18 x 1
Terminal TypeCable
Housing MaterialPPS
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max36 V
Application
Communication Interface
Sensing Distance8 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length60
Switching Frequency Max2 kHz
Dimensions
Electrical ConnectionCable
