Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 36 V
Output TypePNP/NPN
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP67
Reverse Polarity ProtectionYes
Mounting TypeNon-flush
Thread SizeM18 x 1
Terminal Type4-Pin M12 Connector
Housing MaterialPlastic
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max36 V
Application
Communication Interface
Sensing Distance8 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length70 mm
Switching Frequency Max2 kHz
Dimensions
Electrical Connection4-Pin M12 Connector
