Technical Reference

Technical Specifications

AttributeValue
Supply Voltage12 V to 24 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-25
IP RatingIP65, IP69K, IP67
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread SizeM30 x 1.5
Terminal Type3-Pin Connector
Housing MaterialNickel Plated Brass
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/ApprovalsCSA, CE, UL, IEC 60068-2-6, IEC 60529, E2, EN/IEC 61508, IEC 60068-2-27, EN/ISO 13849-1
BrandTelemecanique Sensors
Supply Voltage DC Max24 V
Application
Communication Interface
Sensing Distance10 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length54
Switching Frequency Max1 kHz
Dimensions
Electrical Connection3-Pin Connector
