Technical Reference

Technical Specifications

AttributeValue
Mounting TypeNon-flush
Thread SizeM30 x 1.5
Terminal Type4-Pin M12 Connector
Housing MaterialNickel Plated Brass
Body StyleCylindrical
Supply Voltage12 V to 48 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-25
IP RatingIP65, IP69K, IP67
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/ApprovalsCSA, UL Certified, TUV, IEC 60068-2-6, IEC 62061, IEC 60529, E2, IEC 60068-2-27, EN/ISO 13849-1
BrandTelemecanique Sensors
Supply Voltage DC Max58 V
Application
Communication Interface
Sensing Distance30 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length64
Switching Frequency Max0.5 kHz
Dimensions
Electrical Connection4-Pin M12 Connector
