Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 30 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-25
IP RatingIP69K, IP68
Reverse Polarity ProtectionYes
Mounting TypeNon-flush
Thread SizeM30 x 1.5
Terminal Type4-Pin M12 Connector
Housing MaterialStainless Steel
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max24 V
Application
Communication Interface
Sensing Distance40 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length63.5
Switching Frequency Max0.09 kHz
Dimensions
Electrical Connection4-Pin M12 Connector
