Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM8 x 1
Terminal Type0
Housing MaterialNickel Plated Brass
Body StyleCylindrical
Supply Voltage12 V to 24 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingPartial
Minimum Operating Temperature-25
IP RatingIP65, IP67
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/ApprovalsCSA, UL Certified, CE, IEC 60068-2-6, IEC 60529, IEC 60068-2-27
BrandTelemecanique Sensors
Supply Voltage DC Max24 V
Application
Communication Interface
Sensing Distance1.5 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length42
Switching Frequency Max1 kHz
Dimensions
Electrical Connection
