Technical Reference

Technical Specifications

AttributeValue
Supply Voltage20 V to 264 Vac/dc
Output Type
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP65, IP69K, IP67
Reverse Polarity Protection
Mounting TypeFlush
Thread Size
Terminal Type2m Cable, 3-Wire
Housing MaterialPBT, Plastic
Body StyleRectangular
ManufacturerTelemecanique Sensors
Shape
Series
Depth40
Supply Voltage AC240 V
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max240 V
Application
Communication Interface
Sensing Distance15 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current300 mA
Short Circuit Overload Protection
Length40
Switching Frequency Max0.05 kHz
Dimensions40 x 117 x 40 mm
Width117
Electrical Connection3-Wire, 2 m Cable
