Technical Reference

Technical Specifications

Supply Voltage20 V to 264 Vac/dc
Output Type
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
Minimum Operating Temperature-25 °C
IP RatingIP65, IP69K, IP67
Reverse Polarity Protection
Mounting TypeFlush
Thread Size
Terminal Type3-Pin M8 Connector
Housing MaterialPBT, Plastic
Body StyleRectangular
ManufacturerTelemecanique Sensors
Depth40 mm
Supply Voltage AC240 V
Hazardous Area Certification
BrandTelemecanique Sensors
Supply Voltage DC Max240 V
Communication Interface
Sensing Distance20 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current300 mA
Short Circuit Overload Protection
Length40 mm
Switching Frequency Max0.05 kHz
Dimensions40 x 117 x 40 mm
Width117 mm
Electrical Connection3-Pin M8 Connector
