Technical Reference

Technical Specifications

Supply Voltage20 V to 264 Vac/dc
Output Type
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
Minimum Operating Temperature-25 °C
IP RatingIP67
Reverse Polarity Protection
Mounting TypeNon-flush
Thread Size
Terminal Type3-Pin M8 Connector
Housing MaterialPlastic
Body StyleRectangular
ManufacturerTelemecanique Sensors
Depth26 mm
Supply Voltage AC264 V
Hazardous Area Certification
BrandTelemecanique Sensors
Supply Voltage DC Max264 V
Communication Interface
Sensing Distance60 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current300 mA
Short Circuit Overload Protection
Length80 mm
Switching Frequency Max0.15 kHz
Dimensions80 x 80 x 26 mm
Width80 mm
Electrical Connection3-Pin M8 Connector
