Technical Reference

Technical Specifications

Output TypePNP
Maximum Operating Temperature60
Maximum DC Voltage30 V
Minimum Operating Temperature-40
IP RatingIP69K, IP67
Detection Range5000 mm
Standards MetcULus Certified, UL Certified, Ecolab Certified, IEC 60068-2-6, CE Certified, IEC 60529, IEC 60068-2-27, DIN 40050
Mounting Type
Thread Size
Terminal TypeConnector M12 - 5 Pin
Housing MaterialABS, PC
Body StyleCompact Rectangular
ManufacturerTelemecanique Sensors
Optical TechnologyPhotoelectric
Detection TypeRetro-reflective
Sensor TypeCompact
Light SourceInfrared LED
Maximum Current60 mA
Hazardous Area Certification
Switching Mode
BrandTelemecanique Sensors
Communication Interface
Response Time2 ms
Electrical ConnectionM12 5 Pin Connector
