Technical Specifications

AttributeValue
Output TypeNO/NC
Maximum Operating Temperature55
Maximum DC Voltage24 V
Minimum Operating Temperature-25
IP RatingIP67
Detection Range10000 mm
Mounting Type
Thread Size
Terminal TypeConnector M8 - 4 Pin
Housing MaterialPBT
Body StyleRectangular
Standards Met
ManufacturerTelemecanique Sensors
Optical Technology
Detection TypeThrough Beam
Series
Sensor TypeBlock
Light SourceInfrared LED
Maximum Current100 mA
Hazardous Area Certification
Switching Mode
BrandTelemecanique Sensors
Communication Interface
Response Time2 ms
Electrical ConnectionM8 4 Pin Connector
