PRES TRANS 40BAR 4-20MA

Technical Reference

Attribute	Value
Mounting Type	Thread Mount
Housing Material	Stainless Steel 303
Supply Voltage	12 V dc-24 V dc
Output Type	4-20 mA
Maximum Operating Temperature	+85 °C
Minimum Operating Temperature	-30 °C
IP Rating	IP65, IP69K, IP67
Manufacturer	Telemecanique Sensors
Series
Media Monitored	Refrigeration Fluid, Hydraulic Oil, Gas, Fresh Water, Air
Maximum Pressure Reading	40 bar
Brand	Telemecanique Sensors
Accuracy %	±0.5%
Communication Interface
Response Time	2 ms
Process Connection	G 1/4A
Pressure Type
Maximum Switching Current	23 mA
Pressure Reading Min	0 bar
Electrical Connection	4-Pin M12 Male Connector
