Technical Specifications

AttributeValue
Supply Voltage24 V dc
Output Type0 - 10 V
Maximum Operating Temperature85
Minimum Operating Temperature-30
IP RatingIP65
Mounting TypeCable Mount
Housing MaterialFPM, Ceramic, Stainless Steel 316L
ManufacturerTelemecanique Sensors
Series
Media MonitoredHydraulic Oil, Gas, Fresh Water, Air
Maximum Pressure Reading0.5 bar
Hazardous Area Certification
Calibrated
BrandTelemecanique Sensors
Accuracy %0.001
Communication Interface
Response Time2 ms
Process ConnectionG 1/4A
Pressure TypeDifferential
For Use With
Maximum Switching Current7 mA
Pressure Reading Min0 bar
Electrical Connection3-Pin DIN 43650 Male Connector
