Technical Specifications

Supply Voltage5 V dc
Output Type0.5 - 4.5 V
Maximum Operating Temperature100
Minimum Operating Temperature-40
IP RatingIP65, IP69K, IP67
Mounting TypeThread Mount
Housing MaterialStainless Steel AISI 316L, Fluorocarbon FPM
ManufacturerTelemecanique Sensors
Media MonitoredHydraulic Oil, Fresh Water, Air
Maximum Pressure Reading250 bar
Hazardous Area Certification
BrandTelemecanique Sensors
Accuracy %±0.5%
Communication Interface
Response Time2 ms
Process ConnectionG 1/4
Pressure Type
For Use With
Maximum Switching Current7 mA
Pressure Reading Min0 bar
Electrical Connection3-Pin DEUTSCH Connector DT04-3P
