Please note: Some technical details are unavailable for this product

Technical Specifications

AttributeValue
Supply Voltage12 V to 48 V
Output TypeNPN
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity Protection
Mounting TypeNon-flush
Thread Size
Terminal Type2m Cable, 3-Wire
Housing MaterialPlastic
Body StyleRectangular
ManufacturerTelemecanique Sensors
Shape
Series
Depth100
Hazardous Area Certification
Standards/ApprovalsCCC Certificate
BrandTelemecanique Sensors
Supply Voltage DC Max48 V
Application
Communication Interface
Sensing Distance60 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length80
Switching Frequency Max0.01 kHz
Dimensions80 x 40 x 100 mm
Width40
Electrical Connection3-Wire, 2 m Cable
