Technical Reference

Technical Specifications

AttributeValue
Supply Voltage12 V to 48 V
Output Type
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-25 °C
IP RatingIP69K, IP68
Reverse Polarity Protection
Mounting TypeFlush
Thread SizeM30 x 1.5
Terminal TypeCable
Housing Material
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Application
Communication Interface
Sensing Distance10 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current10 mA
Short Circuit Overload Protection
Length62 mm
Switching Frequency Max2 kHz
Dimensions
Electrical ConnectionCable
