Technical Reference

Technical Specifications

AttributeValue
Supply Voltage20 V to 264 Vac/dc
Output Type
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-25 °C
IP RatingIP65, IP69K, IP67
Reverse Polarity Protection
Mounting TypeFlush
Thread Size
Terminal Type5-Pin M12 Connector
Housing Material
Body StyleRectangular
ManufacturerTelemecanique Sensors
Shape
Series
Depth117 mm
Supply Voltage AC264 V
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Application
Communication Interface
Sensing Distance20 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current1.5 mA
Short Circuit Overload Protection
Length40 mm
Switching Frequency Max0.05 kHz
Dimensions40 x 40 x 117 mm
Width40 mm
Electrical Connection5-Pin M12 Connector
