Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread Size
Terminal Type4-Pin M12 Connector
Housing Material
Body StyleRectangular
Supply Voltage15 V to 36 V
Output TypeAnalogue
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-25
IP RatingIP65, IP69K, IP67
Reverse Polarity Protection
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Application
Communication Interface
Sensing Distance25 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current4 mA
Short Circuit Overload Protection
Length117
Switching Frequency Max
Dimensions
Electrical Connection4-Pin M12 Connector
