Technical Reference

Technical Specifications

AttributeValue
Mounting TypeNon-flush
Thread Size
Terminal TypeCable
Housing MaterialPBT
Body StyleRectangular
Supply Voltage15 V to 36 V
Output Type
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-25 °C
IP RatingIP65, IP69K, IP67
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Depth118.3 mm
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max24 V
Application
Communication Interface
Sensing Distance25 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current
Short Circuit Overload Protection
Length40 mm
Switching Frequency Max0.055 kHz
Dimensions40 x 40 x 118.3 mm
Width40 mm
Electrical ConnectionCable
