Technical Reference

Technical Specifications

AttributeValue
Mounting Type
Thread SizeM18 x 1
Terminal Type4-Pin M12 Connector
Housing MaterialPlastic
Body StyleCylindrical
Supply Voltage10 V to 30 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyCapacitive
ShieldingUnshielded
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max38 V
Application
Communication Interface
Sensing Distance8 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency100 Hz
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length78
Switching Frequency Max
Dimensions
Electrical Connection4-Pin M12 Connector
