Technical Reference

Technical Specifications

AttributeValue
Mounting Type
Thread Size
Terminal TypeConnector M8 - 4 Pin
Housing MaterialPolyamide
Body StyleFork
Output TypeNPN/PNP
Maximum Operating Temperature60
Maximum DC Voltage24 V
Minimum Operating Temperature-20
IP RatingIP65
Detection Range
Standards Met
ManufacturerTelemecanique Sensors
Optical TechnologyPhototransistor
Detection TypeThrough Beam
Series
Sensor TypeFork
Light SourceInfrared LED
Maximum Current100 mA
Hazardous Area Certification
Switching Mode
BrandTelemecanique Sensors
Communication Interface
Response Time0.02 ms
Electrical ConnectionM8 4 Pin Connector
