Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 58 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingShielded
Minimum Operating Temperature-25
IP RatingIP65, IP68
Reverse Polarity ProtectionYes
Mounting TypeNon-flush
Thread SizeM12 x 1
Terminal TypeCable
Housing MaterialNickel Plated Brass
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Supply Voltage AC48 V
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max48 V
Application
Communication Interface
Sensing Distance7 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length55
Switching Frequency Max2.5 kHz
Dimensions
Electrical ConnectionCable
