Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread Size
Terminal Type4-Pin M12 Connector
Housing MaterialPlastic
Body StyleRectangular
Supply Voltage12 V to 48 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP65, IP69K, IP67
Reverse Polarity Protection
ManufacturerTelemecanique Sensors
Shape
Series
Depth117
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max48 V
Application
Communication Interface
Sensing Distance16 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload Protection
Length40
Switching Frequency Max0.3 kHz
Dimensions40 x 40 x 117 mm
Width40
Electrical Connection4-Pin M12 Connector
