Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread Size
Terminal Type3-Pin M8 Connector
Housing MaterialPBT
Body StyleRectangular
Supply Voltage10 V to 36 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingShielded
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Depth15
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max24 V
Application
Communication Interface
Sensing Distance12 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current100 mA
Short Circuit Overload ProtectionYes
Length40
Switching Frequency Max1 kHz
Dimensions40 x 40 x 15 mm
Width40
Electrical Connection3-Pin M8 Connector
