Technical Reference

Technical Specifications

Supply Voltage12 V to 48 V
Output TypeNPN
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
Minimum Operating Temperature-25 °C
IP RatingIP65, IP69K, IP67
Reverse Polarity Protection
Mounting Type
Thread Size
Terminal Type3-Pin M8 Connector
Housing MaterialPlastic
Body StyleRectangular
ManufacturerTelemecanique Sensors
Depth117 mm
Hazardous Area Certification
BrandTelemecanique Sensors
Supply Voltage DC Max48 V
Communication Interface
Sensing Distance40 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload Protection
Length40 mm
Switching Frequency Max0.2 kHz
Dimensions40 x 40 x 117 mm
Width40 mm
Electrical Connection3-Pin M8 Connector
