Technical Reference

Technical Specifications

AttributeValue
Supply Voltage12 V to 24 V
Output TypePNP
Maximum Operating Temperature60
Sensor TechnologyUltrasonic
Shielding
Minimum Operating Temperature0
IP RatingIP67
Reverse Polarity ProtectionYes
Mounting Type
Thread SizeM18 x 1
Terminal Type4-Pin M12 Connector
Housing MaterialBrass
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max36 V
Application
Communication Interface
Sensing Distance50 mm
Transducer Frequency
Accessory Type
For Use With
Switching FrequencyLess than or equal to 80 Hz
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length75
Switching Frequency Max
Dimensions
Electrical Connection4-Pin M12 Connector
