Technical Reference

Technical Specifications

AttributeValue
Supply Voltage12 V to 24 V
Output TypePNP
Maximum Operating Temperature65
Sensor TechnologyUltrasonic
Shielding
Minimum Operating Temperature-20
IP RatingIP67
Reverse Polarity ProtectionYes
Mounting Type
Thread SizeM18 x 1
Terminal Type3-Pin M8 Connector
Housing MaterialValox
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max24 V
Application
Communication Interface
Sensing Distance500 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current100 mA
Short Circuit Overload ProtectionYes
Length63.7
Switching Frequency Max
Dimensions
Electrical Connection3-Pin M8 Connector
