Technical Specifications

AttributeValue
Output Type
Maximum Operating Temperature55
Maximum DC Voltage24 V
Minimum Operating Temperature-25
IP RatingIP65, IP67
Detection Range1500 mm
Standards Met
Mounting Type
Thread Size
Terminal TypeCable
Housing MaterialNickel Plated Brass
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Optical Technology
Detection TypeThrough Beam
Series
Sensor TypeCylindrical
Light SourceInfrared LED
Maximum Current100 mA
Hazardous Area Certification
Switching Mode
BrandTelemecanique Sensors
Communication Interface
Response Time2 ms
Electrical ConnectionCable
