Technical Specifications

AttributeValue
Standards Met
Output TypeDiscrete
Maximum Operating Temperature55
Maximum DC Voltage24 V
Minimum Operating Temperature-25
IP RatingIP65, IP67
Detection Range4000 mm
Mounting Type
Thread Size
Terminal TypeConnector M12 - 4 Pin
Housing MaterialNickel Plated Brass
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Optical Technology
Detection TypeThrough Beam
SeriesXUB
Sensor TypeCylindrical
Light SourceInfrared LED
Maximum Current100 mA
Hazardous Area Certification
Switching Mode
BrandTelemecanique Sensors
Communication Interface
Response Time2 ms
Electrical ConnectionM12 4 Pin Connector
